Members Birthdays
|
|
13th February 2021
|
 |
Senior Master Custom Bike Builder
|
|
Join Date: May 2010
Location: Pottstown PA.
Posts: 14,492 Sportster/Buell Model: xlch Sportster/Buell Year: 1960
|
|
whoa.they're all bronze forks.D.D.'s favorite.
__________________
72 1000cc barrels and heads, s&s 41/2'' flywheels, sifton cams, s&s super B w/ zippers thunderjet w/yost powertube, andrews gears,and shafts, competition engineering kevlar wet or dry clutch, 72 oil pump, morris magneto w/auto advance and single fire module, cycle electric generator w/electronic regulator,73 cu.in.
|
13th February 2021
|
|
Senior Master Custom Bike Builder
|
|
Join Date: May 2010
Location: Pottstown PA.
Posts: 14,492 Sportster/Buell Model: xlch Sportster/Buell Year: 1960
|
|
i had i sticker i liked and wanted to put on the back of my helmet but had the same creasing problem  |
13th February 2021
|
|
Custom Bike Builder
|
|
Join Date: Dec 2014
Location: Phoenix
Posts: 2,485 Sportster/Buell Model: xlch Sportster/Buell Year: 1964 Sportster/Buell Model #2: XLCH IR EFI Sportster/Buell Year #2: 1971 Other Motorcycle Model: BMW K1200RS Other Motorcycle Year: 2001
|
|
Quote:
Originally Posted by brucstoudt
whoa.they're all bronze forks.D.D.'s favorite.
|
Yeah, those are just the spares I carry in my tool roll.....
Can we mention DD around here?? He left us waiting here with our notebooks out mid semester!!
I’d settle for the night school course if he came back around...(c’mon Doc, I know your listening!) |
13th February 2021
|
|
XL FORUM TEAM MEMBER
|
|
Join Date: May 2013
Location: East Midlands UK
Posts: 1,813 Sportster/Buell Model: XLCH Sportster/Buell Year: 1976 Sportster/Buell Model #2: XLCH Sportster/Buell Year #2: 74/5
|
|
You make a valid point Iron Mike, guilty as charged. I rarely venture outside the main IH section of the forum but should do so more.
Paul
Sent from my SM-G935U using Tapatalk
__________________
|
13th February 2021
|
|
XL FORUM TEAM MEMBER
|
|
Join Date: May 2013
Location: East Midlands UK
Posts: 1,813 Sportster/Buell Model: XLCH Sportster/Buell Year: 1976 Sportster/Buell Model #2: XLCH Sportster/Buell Year #2: 74/5
|
|
Quote:
Originally Posted by brucstoudt
i had i sticker i liked and wanted to put on the back of my helmet but had the same creasing problem |
I found gentle curves are ok, had no problem with the oil tank. Sharper curves though are beyond my ability with vinyl.
Paul
Sent from my SM-G935U using Tapatalk |
27th February 2021
|
|
XL FORUM TEAM MEMBER
|
|
Join Date: May 2013
Location: East Midlands UK
Posts: 1,813 Sportster/Buell Model: XLCH Sportster/Buell Year: 1976 Sportster/Buell Model #2: XLCH Sportster/Buell Year #2: 74/5
|
|
Trans parts all arrived now so trying to set gear spacing. Both sliding gears will move back & fore on their shafts - 25 thou on M/S, 30 thou on C/S with trans together on bench.
M/S sliding gear is within specs both sides either end of that movement so no problem.
C/S 3-1 spacing no issues, I can sort that last easy enough.
C/S 2-3 spacing has me scratching my head. Spacing is either 32Thou or 62Thou, depending which end of it's movent on the shaft the gear is. Should I measure the spacing with the gear in the middle of it's 30 Thou travel? Then it would be 47 Thou so all good. Tried several sizes of shift fork and this is as close as I can get it.
Stumped by this, the trans on my 76 had very little sliding gear movement in neutral on the bench.
Paul
Sent from my SM-G935U using Tapatalk
|
28th February 2021
|
|
XL FORUM TEAM MEMBER
|
|
Join Date: May 2013
Location: East Midlands UK
Posts: 1,813 Sportster/Buell Model: XLCH Sportster/Buell Year: 1976 Sportster/Buell Model #2: XLCH Sportster/Buell Year #2: 74/5
|
|
Yoshi figured it out - the BT top hats I have allow a bit of movement so that is why the sliding gear has a bit of left to right movement. I've ordered a pack of 10 more and will use the 2 that measure the biggest diameter in the pack. The IH ones and BT ones I have all measure .370. If the new ones are all the same I'll just have to set the spacing with the sliding gears in the middle of their travel and leave it at that.
Paul
|
|
