Default Gear charts for a Sportster

I posted a gear chart for a Sportster. It will work for any car or motorcycle up thru a 6 speed. The gear ratios "I think" are correct based on the numbers in my owners manual. I did not take a gearbox apart to count teeth on the gears to verify. The numbers in the yellow cells can be changed to anything you wish. Have fun.

http://www.ncs-stl.com/motorcycle/SportsterGearing.xls

AW

Reply With Quote
  #2
Old 12th January 2007
crharvel's Avatar
crharvel crharvel is offline
Biker

Join Date: Dec 2006
Posts: 31
Sportster/Buell Model: XL1200C
Sportster/Buell Year: 2005
crharvel has disabled reputation
Default

Excellent piece of Excel magic! This is a great way to model potential driveline changes.
__________________
[FONT=Arial Narrow][COLOR=black][URL="http://xlforum.net/photopost/showgallery.php/ppuser/13121/cat/500"][COLOR=blue][B]Yes.... it looks just like yours...and the other 900 in the gallery[/B][/COLOR].[/URL] [/COLOR][/FONT]
[FONT=Arial Narrow][/FONT]
[FONT=Arial Narrow]This is where I am supposed to make a witty comment about "paying taxes" right?[/FONT]
Reply With Quote
  #3
Old 12th January 2007
cwissler's Avatar
cwissler cwissler is offline
Harley Engineer

Join Date: Jul 2006
Location: Indiana
Posts: 319
Sportster/Buell Model: xlh
Sportster/Buell Year: 1996
Reputation: 247
cwissler is on a distinguished roadcwissler is on a distinguished roadcwissler is on a distinguished road
Default

Another piece of great info from the XLForum![IMG][/IMG]
__________________
Work To Ride, Ride To Work!
Reply With Quote
  #4
Old 12th January 2007
gbinman's Avatar
gbinman gbinman is offline
Biker

Join Date: Aug 2006
Location: Highland Village, Texas
Posts: 53
Sportster/Buell Model: none
Sportster/Buell Year: 2005
Other Motorcycle Model: HD Road Glide SE
Other Motorcycle Year: 2003
Reputation: 31
gbinman is an unknown quantity at this point
Default

Quote:
Originally Posted by whittlebeast View Post
I posted a gear chart for a Sportster. It will work for any car or motorcycle up thru a 6 speed. The gear ratios "I think" are correct based on the numbers in my owners manual. I did not take a gearbox apart to count teeth on the gears to verify. The numbers in the yellow cells can be changed to anything you wish. Have fun.

http://www.ncs-stl.com/motorcycle/SportsterGearing.xls

AW

Interesting. It is ratio'd for a 1200 US.

I have been looking at this to modify it for ('05) 883 US gearing. I changed the primary ratio to 57/34 and the "Small Gear" from 29 to 28.

Are there other changes needed?

My manual expresses the overall gear rations differently... I haven't yet figured out how to correlate them with your ratios.

Overall Gear Ratios
Gear -- 883 US ---1200 US
1 -----10.944 ---- 9.454
2 ----- 7.524 ---- 6.5
3 ----- 5.834 ---- 5.04
4 ----- 4.806 ---- 4.152
5 ----- 4.071 ---- 3.517

Hints?

Gary
Reply With Quote
  #5
Old 13th January 2007
ncst8er ncst8er is offline
Biker

Join Date: Jul 2005
Posts: 94
Reputation: 10
ncst8er is an unknown quantity at this point
Default

The manual is showing the overall ratio which is the gear ratio x primary ratio x final ratio or for fifth gear: 1.0 x (57/34) x (68/28) = 4.071
Reply With Quote
  #6
Old 13th January 2007
whittlebeast's Avatar
whittlebeast whittlebeast is offline
Senior Master Custom Bike Builder

Join Date: Dec 2006
Posts: 4,992
Sportster/Buell Model: 1200 Low
Sportster/Buell Year: 2007
Other Motorcycle Model: Yamaha FZ1
Other Motorcycle Year: 2008
whittlebeast has disabled reputation
Default

Just do it like this
Reply With Quote
  #7
Old 14th January 2007
gbinman's Avatar
gbinman gbinman is offline
Biker

Join Date: Aug 2006
Location: Highland Village, Texas
Posts: 53
Sportster/Buell Model: none
Sportster/Buell Year: 2005
Other Motorcycle Model: HD Road Glide SE
Other Motorcycle Year: 2003
Reputation: 31
gbinman is an unknown quantity at this point
Default

thanks for the tip, Whittlebeast.

Gary
Reply With Quote
  #8
Old 14th January 2007
decman decman is offline
Post no Avatars!

Join Date: Jan 2005
Location: Dubois, WY
Posts: 3,735
Sportster/Buell Model: 1200S
Sportster/Buell Year: 2001
Sportster/Buell Model #2: XLH-883D
Sportster/Buell Year #2: 1988
Other Motorcycle Model: FXDXT
Other Motorcycle Year: 2001
Reputation: 1716430
decman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond reputedecman has a reputation beyond repute
Default

The ratio for a Baker 6th gear is 0.86
