Default Dyno Chart Reference: 883 (all stock and taxes paid)

Here's where to post your dyno charts for 883s.

Please read these instructions before posting here.

The instructions include an example post of what what your post should look like.
__________________
Folkie
Super Moderator
South East England Riders
'The green machine'

Last edited by Folkie; 30th May 2012 at 21:57..
Reply With Quote
  #2
Old 28th May 2007
cjburr's Avatar
cjburr cjburr is offline
Master Custom Bike Builder

Join Date: Sep 2005
Posts: 3,300
Sportster/Buell Model: Sportster 883/1250 Stage3
Sportster/Buell Year: 2006
Sportster/Buell Model #2: Buell S1 White Lightning
Sportster/Buell Year #2: 1998
Other Motorcycle Model: BMW K1300S
Other Motorcycle Year: 2009
Reputation: 5189
cjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nice
Default Stage1 883



V&H Shortshot Staggereds
Forcewinder A/C
__________________
My Other Toy Goes Mach 25
Reply With Quote
  #3
Old 10th June 2007
AZFlyingDiver's Avatar
AZFlyingDiver AZFlyingDiver is offline
The Horse is Un-Dead

Join Date: Apr 2005
Location: Valley of the Sun
Posts: 1,393
Sportster/Buell Model: XL 883 Custom (Stage 1)
Sportster/Buell Year: 2005
Reputation: 6200
AZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really niceAZFlyingDiver is just really nice
Default





Stage 1 XL883C: S&S air cleaner, Cycle Shack slip-ons, rejetted carb (dyno not too bad for an 883, I think)...

On the "someday" list is punching it out with the NRHS 88" kit - but not until I have something else to ride so it may be a little while...
__________________
'05 XL883C in Black Cherry (Stage 1, etc.)

'05 883C (living at 1100' above sea level near Phoenix, AZ)
S&S a/c, CS slash-cut slip-ons
45/175 jets, 2.75 turns out on the mixture screw, 1 needle shim
52.3HP, 46.2TQ

RIP Mr. Jimi and Johnny G...

Last edited by AZFlyingDiver; 10th June 2007 at 01:52..
Reply With Quote
  #4
Old 23rd June 2007
mstngjoe's Avatar
mstngjoe mstngjoe is offline
Know It All

Join Date: May 2007
Location: Milwaukie, Oregon
Posts: 158
Other Motorcycle Model: Softail Custom
Other Motorcycle Year: 2007
Reputation: 50
mstngjoe is an unknown quantity at this point
Default

'07 XL 883, Stage 1 (see sig).

The closed loop (steady state cruise) a/f ratio was 14.69.

This is the WOT run a/f ratios (uncorrected tq/hp numbers):

RPM x1000 hp ft-lbs Air/Fuel
2.70 24.05 46.80 13.26
2.80 25.02 46.94 13.44
2.90 25.73 46.60 13.59
3.00 26.50 46.39 13.73
3.10 27.38 46.39 13.91
3.20 28.18 46.24 14.05
3.30 29.06 46.25 13.97
3.40 29.78 46.01 13.80
3.50 30.73 46.11 13.67
3.60 31.38 45.78 13.56
3.70 32.03 45.47 13.43
3.80 33.03 45.65 13.20
3.90 34.02 45.82 12.98
4.00 35.18 46.19 12.81
4.10 36.52 46.79 12.64
4.20 37.89 47.38 12.46
4.30 39.07 47.72 12.30
4.40 40.15 47.93 12.25
4.50 41.47 48.40 12.26
4.60 42.50 48.53 12.28
4.70 43.75 48.89 12.31
4.80 44.92 49.15 12.35
4.90 46.00 49.30 12.37
5.00 46.56 48.90 12.47
5.10 47.09 48.49 12.61
5.20 48.12 48.61 12.64
5.30 49.08 48.63 12.55
5.40 49.81 48.45 12.46
5.50 50.53 48.25 12.49
5.60 50.73 47.58 12.59
5.70 50.25 46.31 12.67
5.80 50.78 45.98 12.65
5.90 50.49 44.95 12.55

Dyno sheet attached:
Attached Images
File Type: jpg Dyno1XL883.jpg (132.0 KB, 480 views)
__________________
[SIGPIC][/SIGPIC]
2007 Softail Custom, Cobalt Pearl/Pewter Pearl, Khrome Werks HP+ slip-ons, ISO grips & pegs.

Last edited by mstngjoe; 24th June 2007 at 13:08.. Reason: Add info on a/f ratio
Reply With Quote
  #5
Old 23rd June 2007
Sleeper Sleeper is offline
Poser Extraordinaire

Join Date: Jun 2005
Posts: 3,217
Sportster/Buell Model: 883R Stage 0.5
Sportster/Buell Year: 2002
Sportster/Buell Model #2: Cushman Lowrider
Other Motorcycle Model: Briggs & Stratton Chopper
Reputation: 318775
Sleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond reputeSleeper has a reputation beyond repute
Default

2002 883R Horsepower Chart Completely Stock (Large).jpg

2002 883R 100% Stock, Horsepower


2002 883R Torque Chart Completeiy Stock (Large).jpg

2002 883R 100% Stock, Torque
__________________
Dirty Old Dog
Reply With Quote
Know Thy Hog

  #6
Old 30th August 2007
883's Avatar
883 883 is offline
Biker

Join Date: Aug 2007
Location: Hillbillysvill, Florida
Posts: 75
Sportster/Buell Model: XL883 (Standard)
Sportster/Buell Year: 2007
Other Motorcycle Model: Shovel
Other Motorcycle Year: '71
Reputation: 112
883 is on a distinguished road883 is on a distinguished road
Default '07 883 Stock - 1st Dyno Run with CS Tapereds

Stock A/C, stock injection.
2000 miles on scooter at time of Dyno.

Torque



Horsepower:



Stock 2007 883 Specs:



Done @ FLETCHER'S Harley-Davidson, Clearwater, Florida ...aug.2007
__________________
1200R HD Heads P&P Dave Mackie, 1.94" intakes, 1.65" exhausts, SE Pro Smart Tuner
SE Pro Rocker Arms 1.725:1 Ratio, SE 551 Cams, Wiseco 10.5:1 pistons
Zippers Pro Taper Adj. PRods, SuperTrapp Supemegs 2-1 Exhaust, SE A/C.
Reply With Quote
  #7
Old 27th October 2007
cjburr's Avatar
cjburr cjburr is offline
Master Custom Bike Builder

Join Date: Sep 2005
Posts: 3,300
Sportster/Buell Model: Sportster 883/1250 Stage3
Sportster/Buell Year: 2006
Sportster/Buell Model #2: Buell S1 White Lightning
Sportster/Buell Year #2: 1998
Other Motorcycle Model: BMW K1300S
Other Motorcycle Year: 2009
Reputation: 5189
cjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nicecjburr is just really nice
Default

here's mine as an 883 with

Forcewinder A/C
V&H Shortshot Staggereds
Stock carb


Last edited by cjburr; 30th October 2007 at 00:51..
Reply With Quote
  #8
Old 1st October 2008
Gojira's Avatar
Gojira Gojira is offline
Bike Builder

Join Date: Sep 2007
Location: EAST COAST
Posts: 1,844
Sportster/Buell Model: 883r
Sportster/Buell Year: 2003
Other Motorcycle Model: cb750
Other Motorcycle Year: 1974
Reputation: 3017
Gojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the roughGojira is a jewel in the rough
Default

oem thunderstorm heads and pistons,hurricane 2" intake,v&h ss2-r 2-1 exhaust,twin tec 1005s street dual fire multispark advance curve 3,48 pilot 180 main 1.75 turns on mix screw
Reply With Quote
  #9
Old 17th March 2010
jarhead2001 jarhead2001 is offline
Biker

Join Date: Oct 2008
Posts: 41
Sportster/Buell Model: XL 883
Sportster/Buell Year: 2006
Reputation: 10
jarhead2001 is an unknown quantity at this point
Default 06 883 taxes paid


54.85 HP 47.06
883
SE heavy breather
LSR 2-1
SE ignition
Reply With Quote
  #10
Old 17th March 2010
toe's Avatar
toe toe is offline
Custom Bike Builder

Join Date: Nov 2004
Location: So Cal
Posts: 2,352
Sportster/Buell Model: 883C
Sportster/Buell Year: 2000
Reputation: 70233
toe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud oftoe has much to be proud of
Default

Screaming Eagle AC, Cycle Shack Mufflers, no crosspipe protrusion, exhaust venturis, external breather, Yost Power Tube, 44/170 jets, blue needle - slot 2.5, Crane Hi-4 curve 7 race - 35 degrees w/VOES. 55 HP @ 6700, 47 lbft @ 5300

__________________
Ed

The Only Y2K dual-set 883C
So Cal
Reply With Quote
